BSZ0905PNSATMA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PG-TDSON-8
- Description: MOSFET P-CH 30V 40A TDSON-8
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BSZ0905PNSATMA1 Specifications:
- MfrPart.: BSZ0905PNSATMA1
- Mfr: Infineon Technologies
- Description: MOSFET P-CH 30V 40A TDSON-8
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: OptiMOS™
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 40A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 6V, 10V
- RdsOn(Max)@IdVgs: 8.6mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 1.9V @ 105µA
- GateCharge(Qg)(Max)@Vgs: 43.2 nC @ 10 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 3190 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 69W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PG-TDSON-8
- BSZ0905PNSATMA1 Infineon, MOSFET P-CH 30V 40A TDSON-8, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
BSZ0905PNSATMA1, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
