BSZ0501NSIATMA1 Infineon MOSFET N-CH 30V 25A/40A TSDSON
BSZ0501NSIATMA1 Images
BSZ0501NSIATMA1 Images
  • Manufacturer: Infineon Technologies
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PG-TSDSON-8-FL
  • Description: MOSFET N-CH 30V 25A/40A TSDSON
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
BSZ0501NSIATMA1 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
BSZ0501NSIATMA1 Specifications:
  • MfrPart.: BSZ0501NSIATMA1
  • Mfr: Infineon Technologies
  • Description: MOSFET N-CH 30V 25A/40A TSDSON
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: OptiMOS™
  • PartStatus: Active
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 30 V
  • Current-ContinuousDrain(Id)@25°C: 25A (Ta), 40A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
  • RdsOn(Max)@IdVgs: 2mOhm @ 20A, 10V
  • Vgs(th)(Max)@Id: 2V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 33 nC @ 10 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 2000 pF @ 15 V
  • FETFeature: -
  • PowerDissipation(Max): 2.1W (Ta), 50W (Tc)
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: PG-TSDSON-8-FL
  • BSZ0501NSIATMA1 Infineon, MOSFET N-CH 30V 25A/40A TSDSON, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
BSZ0501NSIATMA1, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
