BSM100GD120DN2BOSA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: Module
- Description: IGBT MOD 1200V 150A 680W
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BSM100GD120DN2BOSA1 Specifications:
- MfrPart.: BSM100GD120DN2BOSA1
- Mfr: Infineon Technologies
- Description: IGBT MOD 1200V 150A 680W
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Tray
- Series: -
- PartStatus: Not For New Designs
- IGBTType: -
- Configuration: Three Phase Inverter
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 150 A
- Power-Max: 680 W
- Vce(on)(Max)@VgeIc: 3V @ 15V, 100A
- Current-CollectorCutoff(Max): 2 mA
- InputCapacitance(Cies)@Vce: 6.5 nF @ 25 V
- Input: Standard
- NTCThermistor: No
- OperatingTemperature: 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: Module
- BSM100GD120DN2BOSA1 Infineon, IGBT MOD 1200V 150A 680W, Discrete Semiconductor Products~Transistors - IGBTs - Modules
