BSC159N10LSFGATMA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PG-TDSON-8-1
- Description: MOSFET N-CH 100V 9.4A/63A TDSON
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BSC159N10LSFGATMA1 Specifications:
- MfrPart.: BSC159N10LSFGATMA1
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 100V 9.4A/63A TDSON
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: OptiMOS™
- PartStatus: Not For New Designs
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 9.4A (Ta), 63A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 15.9mOhm @ 50A, 10V
- Vgs(th)(Max)@Id: 2.4V @ 72µA
- GateCharge(Qg)(Max)@Vgs: 35 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2500 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 114W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PG-TDSON-8-1
- BSC159N10LSFGATMA1 Infineon, MOSFET N-CH 100V 9.4A/63A TDSON, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
BSC159N10LSFGATMA1, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
