BSC120N03MSGATMA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PG-TDSON-8-5
- Description: MOSFET N-CH 30V 11A/39A TDSON
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BSC120N03MSGATMA1 Specifications:
- MfrPart.: BSC120N03MSGATMA1
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 30V 11A/39A TDSON
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: OptiMOS™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 11A (Ta), 39A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 12mOhm @ 30A, 10V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 20 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1500 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta), 28W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PG-TDSON-8-5
- BSC120N03MSGATMA1 Infineon, MOSFET N-CH 30V 11A/39A TDSON, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
