AUIRF540ZS Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D2PAK
- Description: MOSFET N-CH 100V 36A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AUIRF540ZS Specifications:
- MfrPart.: AUIRF540ZS
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 100V 36A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: HEXFET®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 36A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 26.5mOhm @ 22A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 63 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1770 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 92W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D2PAK
- AUIRF540ZS Infineon, MOSFET N-CH 100V 36A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
AUIRF540ZS, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
