AIKQ120N60CTXKSA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT TRENCH/FS 600V 160A TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AIKQ120N60CTXKSA1 Specifications:
- MfrPart.: AIKQ120N60CTXKSA1
- Mfr: Infineon Technologies
- Description: IGBT TRENCH/FS 600V 160A TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: Automotive, AEC-Q101, TrenchStop™
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 160 A
- Current-CollectorPulsed(Icm): 480 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 120A
- Power-Max: 833 W
- SwitchingEnergy: 4.1mJ (on), 2.8mJ (off)
- InputType: Standard
- GateCharge: 772 nC
- Td(on/off)@25°C: 33ns/310ns
- TestCondition: 400V, 120A, 3Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- AIKQ120N60CTXKSA1 Infineon, IGBT TRENCH/FS 600V 160A TO247-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
AIKQ120N60CTXKSA1, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
